589nm激光器 50~250mW

  Wavelength

589 nm

  Spatial Mode

Near TEM00

  Output Power

50,… 250mW

  Operation Mode

CW or Modulation

 Modulation

Analog or TTL modulation 0~30Khz

  Linewidth

<0.5 nm

  Polarization

>100:1

  Beam Spot Shape

Circular, aspect ratio<1.1:1

  Pointing Stability

<0.05 mrad

  Beam Diameter(1/e2)

<3 mm

  Beam Divergence

<2  mrad

  Beam Height from Base

29mm

  Power Stability*

<±5% per 2 hrs

  Temperature Stabilizing

TEC

  Warm Up Time

<5 minutes

  Beam Quality (M2)

<2

  Optimum Operating Temperature

20~30oc

  Storage Temperature

10~50oC

  MTTF**

10,000 hrs

  Dimensions

167(L)x77(W)x60(H) mm

Power Supply

178(W)x197(D)x84(H) mm3

Modulation

0~30khz Analog or TTL
