高温油脂试验机

High Temperature Grease Tester

The High Temperature Grease Tester is an excellent tool to determine the life of lubricating greases designed for operation at elevated temperatures.

The grease under test is filled in a bearing as specified by the ASTM D3336 and mounted on a spindle. The bearing is located in the elevated temperature chamber that is used to heat the test grease to the desired tem-perature and maintain the temperature during the test.

The test applies relatively light load and runs the bearing at high speeds. This determines the ability of a grease to provide lubrication to the arrangement at elevated tem-peratures over extended periods of time.

Features

- ASTM 3336 compliant

-Software control and data acquisition

-CompariView for multiple result comparison and reporting

-Auto sequencing of test temperature cycle

-Stainless steel lined oven for clean operating envi-ronment around sample

-Auto shut off on bearing failure with failure mode identification

-PID controlled temperature rise and maintenance

-Torque display with high and low torque cut-off

-Distinctly identifiable failure modes as stipulated in ASTM D3336

-Digital on / off timer with elapsed time indicator

-Digital temperature indicator for bearing and test chamber temperature

-Safety interlocks of instrument and personnel safety.

Example software screen
